JSY1030 intelligent controller

Description:

  • Collect single-phase electrical parameters, including voltage, current, active power, active electric energy, power factor, frequency, etc., with complete information.
  • It adopts special measurement chip and AC true RMS measurement method, with high measurement accuracy.The communication protocol adopts standard Modbus RTU mode, which has good compatibility and is convenient for programming.
  • The over-voltage, under voltage and over-current thresholds can be set. When the controller detects that the voltage or current exceeds the threshold for 5 seconds, it will automatically disconnect the load.
  • RS-485 communication interface with ESD protection circuit.
  • Industrial chips are used, with perfect lightning protection and anti-interference measures to ensure reliability.
  • Beautiful and compact appearance, light weight, excellent and reliable performance.
  • 35mm DIN rail or plate front installation is adopted.

Product Detail

Product Tags

Description

The consumption of electric energy is largely concentrated in low-voltage distribution terminals. In order to strengthen the measurement, assessment and management of terminal electric energy, and facilitate users' on-site use, transformation and upgrading. Jsy1030 intelligent controller aims at the inconvenience of using and installing the traditional wall mounted watt hour meter on site, and designs a miniature guide rail mounted watt hour meter, which has the advantages of high measurement accuracy, strong overload capacity, stable and reliable performance, wide working voltage range and low power consumption. And its small size, light weight, modular structure, can be used with miniature circuit breakers installed in the distribution box to achieve terminal distribution energy measurement.

Technical Parameter

1. Single phase AC input
1) Voltage range: 100V, 220V, etc
2) Current range: AC 32A
3) Signal processing: special measurement chip is used, and 24 bit AD is used
4) Overload capacity: 1.2 times the range is sustainable; Instantaneous (< 20ms) current is 5 times, voltage is 1.2 times, and range is not damaged
5) Input impedance: voltage channel ＞ 1K Ω /v; Current channel ≤ 100m Ω

2. Communication interface
1) Interface type: RS-485 interface
2) Communication protocol: MODBUS-RTU protocol
3) Data format: "n, 8,1"
4) Communication rate: the baud rate of RS-485 communication interface can be set at 1200, 2400, 4800, 9600bps; The baud rate is 9600bps by default

3. Measurement output data
Voltage, current, active power, active electric energy, power factor, frequency and other electrical parameters,

4. Measurement accuracy
Voltage, current and electric quantity: ± 1.0%, active kwh level 1

5. Isolation
RS-485 interface is isolated from power supply, voltage input and current output; Isolation withstand voltage 2000vac

6. Power supply
1) When AC220V power is supplied, the peak voltage shall not exceed 265V; Typical power consumption: ＜ 10va

7. Working environment
1) Working temperature: -20 ~ +55 ℃; Storage temperature: -40 ~ +70 ℃.
2) Relative humidity: 5 ~ 95%, no condensation (at 40 ℃).
3) Altitude: 0~3000 meters
4) Environment: no explosion, corrosive gas and conductive dust, no significant shaking, vibration and impact.

8. Temperature drift
≤100ppm/℃

9. Installation method
35mm DIN rail mount
